Grass KINVARO L80 Liftup Flap Fittings for 430-600mm Cabinet - [Type 5 Spring C]

  • Product code: KL805C
The KINVARO parallel vertical lift flap system offers high stability and will suit a flap weight 7 to 14.6kg. With 3-dimensional adjustment, the L80 allows the use of cornices, pelmets and pelmet lights.
  • Suitable for cabinet height between: 430-600mm
  • Minimum cabinet width 450mm
  • Maximum cabinet width 1200mm
  • Minimum installation depth: 260mm

Availability:

  • Osborne Park: In stock
  • Adelaide: In stock
  • Wangara: Special order
  • Bunbury: Special order
$307.00 kit (incl.GST)
Trade customers: login to view pricing
Information Brochures & Downloads

Product Information

Unsure on what information you need to know? Check out our comprehensive information guide available from the Brochures & Downloads section on this page. Additional technical data is also available as well.

Additional Features
  • Height adjustment: +/- 1.5 mm
  • Lateral adjustment: +/- 1.5 mm
  • Angle adjustment: +/- 1.5 mm
  • Material: Steel
  • Surface: Nickel plated
  • Colour: Telegrey
  • Manufacturer's part number: F152145254

    • Brochures & Downloads

    Grass Kinvaro L80 Technical Data Sheet

    Grass Kinvaro L80 Technical Data Sheet
